Product Details
Place of Origin: Guangdong China
Brand Name: Shareway
Certification: CE UL RoHS ISO9001:2008
Model Number: 7843835400033
Payment & Shipping Terms
Minimum Order Quantity: 100pcs
Price: Supportive
Packaging Details: 500 parts per full reel
Delivery Time: Stock or 3-4 weeks
Payment Terms: TT,Paypal
Supply Ability: 5000K.PCS/Month
Product Name: |
Magnetically Shielded SMT Power Inductor For POL-converter 7843835400033 |
Usage: |
For POL-converter |
Mount: |
Surface Mount |
Product Type:: |
SMT Power Inductor |
Operating Temperature Range: |
-40°C To 125°C |
Inductance: |
0.033 µH |
Package: |
Tape&Reel |
Product Name: |
Magnetically Shielded SMT Power Inductor For POL-converter 7843835400033 |
Usage: |
For POL-converter |
Mount: |
Surface Mount |
Product Type:: |
SMT Power Inductor |
Operating Temperature Range: |
-40°C To 125°C |
Inductance: |
0.033 µH |
Package: |
Tape&Reel |
Magnetically shielded SMT Power Inductor for POL-converter 7843835400033
Characteristics
Applications
Electrical Properties:
| Properties | Test conditions | Value | Unit | Tol. | |
| Inductance | L | 100 kHz/ 10 mA | 0.033 | µH | ±30% |
| Performance Rated Current 1) | I RP,40K | ΔT = 40K | 33.5 | A | max |
| Saturation Current @ 10% | I SAT, 10% | |ΔL/L| < 10 % | 19 | A | typ. |
| Saturation Current @ 30% | I SAT,30% | |ΔL/L| < 30 % | 40 | A | typ. |
| DC Resistance | RDC | @ 20 °C | 0.9 | mΩ | typ. |
| DC Resistance | RDC | @ 20 °C | 1.1 | mΩ | max. |
| Self Resonant Frequency | f res | 682 | MHz | typ. | |
| Operating Voltage | VOP | DC | 80 | V | max. |
Shape and Dimensions:
Product picture:
Magnetically shielded SMT Power Inductor for POL-converter 7843835400033
