Product Name: |
Low Profile Compact THT SMPS Flyback Power Transformer 7492551000 |
Usage: |
For Control And Monitoring Applications |
Product Type:: |
SMPS Flyback Transformer |
Operating Temperature Range: |
–40 ºC To +125 ºC |
Termination Type: |
Through-hole |
Package: |
Tape / Reel |
Product Name: |
Low Profile Compact THT SMPS Flyback Power Transformer 7492551000 |
Usage: |
For Control And Monitoring Applications |
Product Type:: |
SMPS Flyback Transformer |
Operating Temperature Range: |
–40 ºC To +125 ºC |
Termination Type: |
Through-hole |
Package: |
Tape / Reel |
Low profile compact THT SMPS Flyback Power Transformer 7492551000
Characteristics
Applications
Electrical Properties:
| Properties | Test conditions | Value | Unit | Tol. | |
| Inductance | L | N2/ 100 Hz/ 1 V | 400 | µH | min. |
| Rated Current | I R | N1/ ΔT = 40 K | 45 | A | typ. |
| Frequency Range Min & Max | 47-400 | Hz | |||
| DC Resistance 1 | RDC 1 | N1/ 20 °C | 0.27 | mΩ | max. |
| DC Resistance 2 | RDC 2 | N2/ 20 °C | 16.2 | Ω | ±10% |
| Turns Ratio | n | N1 : N2 | 1:500 | ||
| Voltage-µSecond | ∫Udt | N2/ bipolar waveform | 30000 | Vµs | max. |
| Rated Voltage | VR | N2 | 80 | V (DC) | max. |
| Insulation Test Voltage | VT | N1 => N2 | 4000 | V (AC) |
Low profile compact THT SMPS Flyback Power Transformer 7492551000
Shape and Dimensions:
Product picture:
Low profile compact THT SMPS Flyback Power Transformer 7492551000
